RealEco TECO Series 3.6KW-4.2KW Smart Hybrid Solar Inverter

Category: Brand:

Key Features:

  • Pure sine wave solar inverter(on/off Grid)
  • Output power factor 1.0
  • WIFI&GPRS available for IOS and Android
  • Inverter can run without battery
  • One-key restoration to factory Settings
  • Built-in Lithium battery automatic activation
  • Built-in 120A MPPT Solar charge:max 6200W(for 3.6KW/4.2KW),
  • High PV input voltage range 60-500VDC
  • Built-in anti-dust kit for harsh environment
  • Smart battery charge design to optimize battery life
  • Dual output
  • Communication with lithium battery

 120,000

Out of stock

Out of stock

Description

MODEL TECO-3.6KW TECO-4.2KW
Phase 1-Phase
Maximum PV Input Power 6200W 6200W
Rated Output power 3600W 4200W
Maximum Sol ar Charging Cu rrent 120A
GRID-TIE OPERATION
PV INPUT (DC)
Nominal DC Voltage/Maximum DC Voltage 360/500VDC
Start-up Voltage J Initial Feeding Voltage 90VDC/120VDC
MPPT Voltage Range 60-450VDC
Maximum Input Current 1/18A
Nominal Output Voltage 220/230/240VAC
Output Voltage Range 190-253VDC
Nominal Output Current 15.7A 18.2A
Power Factor >0.99
EFFICIENCY
Maximum Conversion Efficiency (DC/AC) 98%
TWO LOAD OUTPUT POWER
Full Load 3600W 4200W
Maxium Main Load 3600W 4200W
Maxium Second Load(battery mode) 1200W 1400W
Maxium Load Cut Off Voltage 26VDC 26VDC
Maxium Load Return Voltage 27VDC 27VDC
OFF-GRID OPERATION
AC INPUT
AC Start-up Voltage / Auto Restart Voltage 120-140VAC/180VAC
Acceptab le Input Voltage Range 90-280VAC or 170-280VAC
Frequency Range 49-51±1 Hz or 59-61±1 Hz
Maximum AC Input Current 30A
PV INPUT (DC)
Nominal DC Voltage/Maximum DC Voltage 360/500VDC
MPPT voltage Range 60-450VDC
Maximum Input Current 1/18A
BATTERY MODE OUTPUT (AC)
Nominal Output Voltage 220/230/240VAC
Output Waveform Pure sine wave
Efficiency (DC to AC) 94%
BATTERY & CHARGER
Nominal DC Voltage 24VDC
Maximum Solar Charging Current 120A
Maximum AC Charging Current 100A
Maximum Charging Current 120A
HYB RID OPERATION
PV INPUT (DC)
Nominal DC Voltage/Maximum DC Voltage 360/500VDC
Start-up Voltage / Initial Feeding Voltage 90VDC/120VDC
MPPT Voltage Range 60-450VDC
Maximum Input Current 1/18A
GRID OUTPUT (AC)
Nominal Output Voltage 220/230/240VAC
Output Voltage Range 190-253VDC
Nominal Output Current 15.7 18.2A
AC INPUT
AC Start-up Voltage I Auto Restart Voltage 120-140VAC/180VAC
Acceptable Input Voltage Range 90-280VACor170-180VAC
Maximum AC Input Current 30A
Maximum AC Charging Current 100A
